LBX4500 RF Shielded Enclosure

LBX4500 RF Shielded Enclosure
Price : 3.95 Lac - 4.10 Lac / 1-10
Get Best Price

MOQ : 1 Piece

Business Type Manufacturer, Exporter
Country of Origin India
Type Rf Shielded Enclosure
Material RF Shielding Material
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Shape
Customised
Feature
Premium Quality
Finishing
Powder Coating
Open Style
Hinged
Installation
Customised
Brand Name
LabiFix Innovations
Application
Wireless Device Testing
Power
230VA/C
Warranty
1 Year
Certificate
ISO 9001:2015 Certified
Filtered Ethernet
10M, 100M, 1G
Filtered USB
2.0 & 3.0
Power filter
AC / DC
RF Ports
SMA, SMB, BNC, TNC, UHF
Fiber optics
ST and Waveguide
Data
DB9, DB15, DB25, DB50, RJ11
Exterior :
26H x 17W x 22D
Interior :
24H x 15W x 20D
Shielding Effectiveness
> 95dB @ 1 GHz > 90dB @ 3 GHz > 85dB @ 6 GHz
Construction
Rugged Steel Welded Construction
Operating Frequency Range
800MHz to 12GHz
Ventilation
High performance shielded Air Vents for adequate air flow
Download
Product Code
LBX4500
Port
Bangalore
Payment Terms
T/T
Delivery Time
30 Days
Packaging Details
We use export-quality inspection and fumigation wooden boxes with a strong construction, making sure that the shielding box will not be damaged in transport. The design is ideal for long distance transportation such as shipping on land or by sea, and can be shipped to any country around the world.



The LBX4500 RF Shielded Test Enclosure supports wireless communication technologies such as 3G, 4G, 5G LTE and Wi-Fi 802.11a/b/g/n/ac/n MIMO and rf electronics. Also, it can be completely customizable, allowing users to choose from a wide range of I/O connectors and enclosures, as well as an array of options for power and  data ports. The RF shielded enclosure is constructed with superior steel and High Grade RF Absorber materials helps dampen signals inside the RF chamber and can be customized for various requirements. The interior space inside the unit allows for larger devices to be tested while still providing high shielding effectiveness of >100dB.



HIGHLIGHTS

  • Higher RF Isolation
  • Completely Customizable Shielded Enclosure
  • High Performance RF Absorber lining
  • User Defined & Interchangeable I/O Connector options
  • Rugged Welded Construction
  • EMI filters on Data Ports
  • RF Fitted Gasket System
  • Powered by AC / DC Power Filter lines
  • Lightweight Rack Mountable or Tabletop Options
  • High performance shielded Air Vents for adequate air flow



TECHNOLOGIES SUPPORT

  • Supports Current and future wireless communication
  • technologies such as 3G, 4G, 5G LTE
  • Wi-Fi 802.11 - all series
  • Wi-Max, GNSS, Bluetooth
  • EMI, RFI test
  • Devise Testing, over the air measurements, Pre-compliance
  • R&D, Product verification, Performance reliability, Quality
