LBX0500 Small RF Shield Box for mobile phone testing

Home › Products › RF Shielded Test Enclosure › LBX0500 Small RF Shield Box For Mobile Phone Testing

LBX0500 Small RF Shield Box for mobile phone testing
LBX0500 Small RF Shield Box for mobile phone testing
Price : 85,000.00 - 1.20 Lac / Unit
Get Best Price

MOQ : 1 Piece

Business Type Manufacturer, Exporter, Supplier
Country of Origin India
Type RF Shielded Enclosure
Material RF Shielding Material
Click to view more

Preferred Buyer From

Location Worldwide
Request to Call Send Enquiry

Product Details

Feature
Premium Quality
Brand Name
LabiFix Innovations
Filtered Ethernet
10M, 100M, 1G
Filtered USB
2.0 & 3.0
Power Filter
Ac / Dc
RF Ports
SMA, N Type, BNC, TNC
Fiber Optics
St & Waveguide
Data
DB9, DB15, DB25, DB50, RJ11
Exterior :
6H x 8W x 11D
Interior :
4H x 6W x 9D
Construction
Rugged Steel Welded Construction
Shielding Effectiveness
> 90dB @ 1 GHz > 90dB @ 3 GHz > 80dB @ 6 GHz
Download
View
Product Code
LBX500
Port
Bangalore
Payment Terms
T/T
Delivery Time
30 Days
Packaging Details
We use export-quality inspection and fumigation wooden boxes with a strong construction, making sure that the shielding box will not be damaged in transport. The design is ideal for long distance transportation such as shipping on land or by sea, and can be shipped to any country around the world.

HIGHLIGHTS

  • Excellent shielding performance
  • Completely Customizable Shielded Enclosure
  • High Performance RF Absorber lining
  • User Defined & Interchangeable I/O Connector options
  • Rugged Welded Construction
  • EMI filters on Data Ports
  • RF Fitted Gasket System
  • Powered by AC / DC Power Filter lines
  • Lightweight Rack Mountable or Tabletop Options
  • High performance shielded Air Vents for adequate air flow



TECHNOLOGIES SUPPORT

  • Supports Current and future wireless communication
  • technologies such as 3G, 4G, 5G LTE
  • Wi-Fi 802.11 - all series
  • Wi-Max, GNSS, Bluetooth
  • EMI, RFI test
  • Devise Testing, over the air measurements, Pre-compliance
  • R&D, Product verification, Performance reliability, Quality
